FUJI Frenic Lift

                                                       Fuji Frenic LIFT Drives

                                                                                Series for lift and hoisting applications

Over the years, Fuji Electric has collected a well established know-how of inverters for lift applications. With this focus in mind, we developed a new inverter, specialized in lift applications with all related requirements: FRENIC-Lift. With FRENIC-Lift LM1S, Fuji Electric is well established in the lift industry, and is ready and well-prepared for the European lift market. Like all Fuji Electric inverters, FRENIC-Lift offers a big variety and many possibilities - and of course finest Japanese high quality. FRENIC-Lift is an ideal inverter for nowadays market of lift applications.

Dedicated inverter for lift applications, User friendly, Low maintenance: Long-life design, Speed control accuracy: + 0.01%

Current loop bandwidth: 500 Hz, Powerful: 200% of rated current for 10 s, 4.0 kW to 45 kW (3 ph 400 V supply)

5.5 kW to 22 kW (3 ph 200 V supply), 2.2 kW (1 ph 200 V supply), TP-G1-ELS (multifunctional keypad, 12 languages available)

Fuji Electric vfd FRENIC-Lift has a high performance vector control

Current response (ACR): 500Hz
Speed control accuracy: ±0.01%

High overload capacity

200% of rated current for 10s*2) (Overload begins from 80% continuous operation with a carrier frequency of 10kHz.)

IM/PMSM common drive

A single AC Drive can control an induction motor (open/closed loop control) and a synchronous motor (the optional PG interface card is required).

Fuji Electric drive FRENIC-Lift series model variations

FRENIC-Lift AC Drives are available in a series with capacities ranging from 5.5 to 22kW for three-phase 200V model. 4.0 to 45kW for three-phase 400V model. 2.2kW for single-phase 200V model.

Applicable to the feedbacks from various pulse generators

Applicable to the inputs by open collector/complementary output as a standard specification (Encoder power supply is switchable between +12V and +15V.)
Applicable to the inputs from the 5V line driver as an option
Applicable to Sin/Cos, Serial interface (EnDat2.1) and Parallel interface (4-bit gray code, UVM 3-bit code)

Fuji Electric inverter FRENIC-Lift Maintenance functions/ Long life design

DC bus capacitor life: 7 years
Electrolytic capacitor life on the printed circuit boards: 7 years
Cooling fan life: 5 years
Life warning signal
Recording and display of cumulative operating time
Recording and display of cumulative operations

Globalization

Safety standards EN61800-5-1:2003, EN954-1 Category3
Sink/source switchable
RS-485 communications (Modbus RTU) is adopted as standard equipment.
CAN Bus is adopted as standard equipment.

Fuji Electric frequency inverter FRENIC-Lift Peripheral support tools (Option)

AC Drive support loader software is provided.
A multi-function keypad (with backlit LCD) makes it possible to copy or edit the function code data.

FRENIC-Lift-Finest drives specialized in lift applications-2024.pdf

FUJI-FRENIC-Lift-English_SI471894F_LM2A_IM_E__3ph_230V_included.pdf

FUJI-FRENIC-Lift-INR-SI47-1909a-E_Lift_LM2__RM_E_.pdf

FUJI-FRENIC-Lift-English_SG_FRENIC_LM2A_CiA417_EN_1_0_2.pdf

FUJI-FRENIC-Lift-English_SG_FRENIC_LM2A_DCP_EN_1_0_0.pdf

FUJI-FRENIC-Lift-English_SG_FRENIC_LM2A_EN_1_4_0__3ph_230V_included_.pdf

FUJI_FRENIC_lift_multifunction_keypad_panel_instruction_manual_TP-G1-LS.pdf

FUJI-FRENIC-Lift-dişlili-redüktörlü-motor-ayar-son.pdf

FUJI-FRENIC-Lift-dişlisiz-motor-ayar-son.pdf

FUJI_FRENIC_Lift_starting_guide_kılavuz_Türkçe.pdf

FUJI-FRENIC-Lift-OPC-LM1-PS1.pdf

FUJI-FRENIC-Lift-OPC-LM1-PR.pdf

FUJI-FRENIC-Lift-OPC-LM1-IL.pdf

ÖZELLİKLER

Asansör uygulamaları için geliştirilmiş
Kullanıcı dostu
Uzun ömürlü dizayn
Hız kontrol hassasiyeti: + 0.01%
Güçlü: 10 saniye boyunca nominal akımın 200%’ü
4.0 kW’dan 45 kW’a kadar geniş ürün yelpazesi (3 ph 400 V besleme)
2.2 kW (1 ph 200 V besleme)
TP-G1-ELS (12 farklı dil desteği sunan fonksiyonel el terminali)

OPSİYONEL KARTLAR

SinCos, EnDat 2.1 encoder kartı (OPC-LM1-PS1)
SinCos, SinCos encoder kartı (OPC-LM1-PR)
5V TTL line driver encoder kartı (OPC-LM1-IL)

Fuji Electric, yılların getirmiş olduğu tecrübe ve bilgi ile harmanlayarak oluşturduğu ‘’know-how’’ sayesinde, asansör uygulamaları için ihtiyaç duyulan özellikleri karşılayan yeni sürücüleri yaratmak için odaklanmıştır. Sektörün yol gösterici firması olan Fuji Electric, FRENIC-Lift serisi sürücüler ile Avrupa asansör sektörüne hitap eden ve geniş bir pazar ağına sahip olan sektörün öncü firmasıdır. Diğer tüm Fuji Electric sürücüleri gibi FRENIC-Lift serisi sürücüler de Japonların yüksek kalitesine sahip olup birden çok asansör uygulamalarında ihtiyaç duyulan gereksinimlere cevap verebilir. FRENIC-Lift, günümüzde, asansör uygulamaları pazarında kullanılan ideal bir sürücüdür.

                                                                  Frenic Lift (3 phase 400 V)
